- Best driving and lifting experience
- AC powered
- High precision driving
- Smooth proportional movements
- Industry leading turning radius
- Utmost versatility
- Able to go through standard doorways
- Mobile pothole protection
- Indoor – outdoor rated
- Minimal maintenance and downtime
- Maintenance free AC motors
- Smart transportability
- Longer lifetime
- Extreme durability
- Optimized total cost of ownership
|
- 24 V electric drive brushless AC motors
- 24 V – 105 Amph C5 batteries
- Battery charge indicator
- Battery level indicator on upper and lower control boxes
- Haulotte ACTIV’Screen on-board diagnostic system
- 2 Swing out trays
- Lateral fork lifting pockets, lifting and tie down points
- Electrical or manual brake release system
- AC power to the platform
- Non-marking tires
|
- Maintenance free batteries
- Pipe cradle
- Swing-door entry gate
- Flashing beacon
- Dual flashing beacons
- Working light
- AC Power to the platform (Standard on US machines)
- Hydraulic oil for cold climates
|
| TECHNICAL DATA |
| Working height |
24 ft 11 in |
| Platform height |
18 ft 11 in |
| Lift capacity |
507 lbs |
| Platform length – outside |
5 ft 8 in |
| Platform length – extended |
8 ft 6 in |
| Extension length |
2 ft 10 in |
| Platform width – outside |
2 ft 5 in |
| Height – stowed |
6 ft 6 in |
| Overall width |
2 ft 7 in |
| Length |
6 ft 3 in |
|
| Wheelbase |
4 ft 6 in |
| Ground clearance |
4 in |
| Ground clearance – Pothole guards deployed |
1 in |
| Drive speed |
0.3 – 2.8 mph |
| Driveable at full height up to |
18 ft 11 in |
| Gradeability |
25 % |
| Tilt alarm |
1.5° – 3° |
| Lift / lower speed |
20 s / 29 s |
|
| Turning radius – outside |
4 ft 11 in |
| Non-marking tires |
12.5 x 4.13 |
| Batteries |
24 V – 130 Ah (C20) |
| Hydraulic system capacity |
1.8 gal |
| Weight |
2,800 lbs |
| Platform size – extended |
8 ft 6 in x 2 ft 5 in |
| Lift capacity – inside |
500 lbs |
| Lift capacity – outside |
500 lbs |
|
